| Specifications |
| Made in | Brand of Korea - Made in China |
| Refrigerant | R410A |
| Type | Inverter AC - 2-way type (cooling and heating) |
| Cooling Capacity | 5,000 / 17,000 / 18,000 Btu/h
10,900 / 48,000 / 48,500 Btu/h
(Low / Medium / High) |
| Heating Capacity | 2,500 / 17,000 / 22,000 Btu/h
10,900 / 48,000 / 48,500 Btu/h
(Low / Medium / High)
|
| Use For Room | Room area 24 - 27 m² or Volume 72 - 81 m³ ( Suitable for living room, office ) |
| Power Input (Ph/V/Hz) | 1 Phase, 220 - 240 V, 50Hz |
| Power consumption (kW) | Làm lạnh: 1.47 / 4.98 / 5.28 kW
Sưởi ấm: 0.73 / 4.98 / 6.45 kW
10,900 / 48,000 / 48,500 Btu/h
(Low / Medium / High) |
| Refrigerant/ Liquid Pipe Diameter (mm) | 6.35 / 12.7 |
| Maximum Pipe Length | 30 m |
| Maximum Elevation Length | 15 m |
| Indoor Unit |
| Indoor Unit Dimensions (mm) | 840 x 204 x 840 (mm) |
| Indoor Unit Net Weight (Kg) | 14.5 (Kg) |
| Panel |
| Panel Dimensions (mm) | 950 x 45 x 950 (mm) |
| Panel Net Weight (Kg) | 5.9 (Kg) |
| Outdoor Unit |
| Outdoor Unit Dimensions (mm) | 790 x 548 x 285 (mm) |
| Outdoor Unit Net Weight (Kg) | 36 (Kg) |
